Chapter 1
1-8 Getting Started
Connectors Reference Guide
Port Name Port Type Page
Back Panel 1-9
CPU Socket LGA1150 CPU Socket 1-12
CPUFAN1~2,SYSFAN1~3 Fan Power Connectors 1-22
DIMM1~4 Memory slots 1-15
JAUD1 Front Panel Audio Connector 1-25
JBAT1 Clear CMOS Jumper 1-27
JCI1 Chassis Intrusion Connector 1-25
JCOM1 Serial Port Connector 1-26
JFP1, JFP2 System Panel Connectors 1-23
JLPT1 Parallel Port Connector 1-26
JPWR1~2 ATX Power Connectors 1-17
JTPM1 TPM Module Connector 1-27
JUSB1~2 USB 2.0 Expansion Connectors 1-24
JUSB3 USB 3.0 Expansion Connector 1-24
M2_1 M.2 Connector 1-21
PCI1~2 PCI Expansion Slots 1-18
PCI_E1~5 PCI Express Expansion Slots 1-18
SATA1~6 SATA Connectors 1-20
SATA_EXP1 SATA Express Connector 1-21
