MSI Z97M GAMING - Manual (Page 22)

Chapter 1
1-8 Getting Started
Connectors Reference Guide
Port Name Port Type Page
Back Panel I/O ports 1-9
AUD_SW1 Audio Power Switch 1-28
AUDPWR1 Direct Audio Power Connector 1-25
CPU LGA1150 CPU Socket 1-11
CPUFAN1~2,SYSFAN1~2 Fan Power Connectors 1-21
DIMM1~4 DDR3 Memory Slots 1-15
JAUD1 Front Panel Audio Connector 1-25
JBAT1 Clear CMOS Jumper 1-29
JCI1 Chassis Intrusion Connector 1-24
JFP1, JFP2 System Panel Connectors 1-22
JPWR1~2 ATX Power Connectors 1-17
JTPM1 TPM Module Connector 1-24
JUSB1~2 USB 2.0 Expansion Connectors 1-23
JUSB3 USB 3.0 Expansion Connector 1-23
M2_1 M.2 Port 1-26
OC1 OC Genie Button 1-27
PCI_E1~E4 PCIe Expansion Slots 1-18
POWER1 Power Button 1-28
RESET1 Reset Button 1-28
SATA1~6 SATA Connectors 1-20
