Chapter 1
1-5
Getting Started
Wireless
LAN
Z87 MPOWER MAX AC
Wi-Fi/Bluetooth expansion module with Intel
®
Dual Band
Wireless-AC 7260 chip.
Supports Wi-Fi 802.11 ac/b/g/n, dual band (2.4GHz, 5GHz) up to
867 Mbps speed.
Supports Intel
®
Wireless Display (WiDi)
■
-
-
-
Z87 MPOWER MAX
Wi-Fi/Bluetooth expansion module with Intel
®
Centrino Wireless-
N 2230 chip.
Supports Wi-Fi 802.11 b/g/n, dual band up to 300 Mbps speed.
Supports Intel
®
Wireless Display (WiDi)
■
-
-
-
Bluetooth
Z87 MPOWER MAX AC
Wi-Fi/Bluetooth expansion module with Intel
®
Dual Band
Wireless-AC 7260 chip.
Supports Bluetooth v4.0 (includes BLE* and Bluetooth 3.0+HS)
■
-
-
Z87 MPOWER MAX
Wi-Fi/Bluetooth expansion module with Intel
®
Centrino Wireless-
N 2230 chip.
Supports Bluetooth v4.0 (includes BLE* and Bluetooth 3.0+HS)
* BLE: Bluetooth Low Energy
■
-
-
Back Panel
Connectors
1x PS/2 keyboard/ mouse port
2x USB 2.0 ports
1x Clear CMOS button
6x USB 3.0 ports
1x Optical S/PDIF OUT connector
2x HDMI ports
1x DisplayPort
1x LAN (RJ45) port
6x OFC audio jacks
■
■
■
■
■
■
■
■
■
Internal
Connectors
1x 24-pin ATX main power connector
2x 8-pin ATX 12V power connectors
8x SATA 6Gb/s connectors
2x USB 2.0 connectors (supports additional 4 USB 2.0 ports)
2x USB 3.0 connectors (supports additional 4 USB 3.0 ports)
2x 4-pin CPU fan connectors
3x 4-pin system fan connectors
1x Clear CMOS jumper
1x Discharge jumper
1x Front panel audio connector
2x System panel connectors
1x Chassis Intrusion connector
14x V-Check points (7x V-Check connectors, 7x V-Check spots)
1x GO2BIOS button
1x Power button
1x Reset button
2x Base Clock control buttons
1x OC Genie button
1x Multi-BIOS switch
1x OC Genie mode switch
1x 2-Digit Debug Code LED
1x Wi-Fi/Bluetooth module connector
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
