Motherboard Specifications
CPU
Support
4th Generation Intel
®
Core™ i7 / Core™ i5 / Core™ i3 / Pentium
®
/
Celeron
®
processors for LGA 1150 socket
■
Chipset
Intel
®
Z87 Express Chipset
■
Memory
Support
4x DDR3 memory slots supporting up to 32GB
Supports DDR3 3000(OC)/ 2800(OC)/ 2666(OC)/ 2600(OC)/
2400(OC)/ 2200(OC)/ 2133(OC)/ 2000(OC)/ 1866(OC)/ 1600/ 1333/
1066 MHz
Dual channel memory architecture
Supports non-ECC, un-buffered memory
Supports Intel
®
Extreme Memory Profile (XMP)
■
■
■
■
■
Expansion
Slots
3x PCIe 3.0 x16 slots (support x16, x8/x8, x8/x4/x4 modes)
4x PCIe 2.0 x1 slots*
* The PCI_E6 slot will be unavailable when install an expansion card in the PCI_E3 slot.
■
■
Onboard
Graphics
2x HDMI ports, supporting a maximum resolution of
4096x2160@24Hz, 24bpp/ 2560x1600@60Hz, 24bpp/
1920x1080@60Hz, 36bpp
1x DisplayPort,
supporting a maximum resolution of
4096x2160@24Hz, 24bpp/ 3840x2160@60Hz, 24bpp
■
■
Multi-GPU
Support
Supports 3-Way AMD
®
CrossFire
TM
Technology*
Supports 2-Way NVIDIA
®
SLI
TM
Technology
* Supports Windows 7 and Windows 8.
■
■
Storage
Intel Z87 Express Chipset
1x mSATA 6Gb/s port*
6x SATA 6Gb/s ports (SATA1~6)*
Supports RAID 0, RAID1, RAID 5 and RAID 10
Supports Intel Smart Response Technology, Intel
®
Rapid Start
Technology and Intel Smart Connect Technology**
ASMedia ASM1061 Chipset
2x SATA 6Gb/s ports (SATA7~8)
* The SATA5 port will be unavailable when install a SSD in the mSATA port.
** Supports Intel Core processors on Windows 7 and Windows 8.
■
-
-
-
-
■
-
USB
Intel Z87 Express Chipset
4x USB 3.0 ports (available through the internal USB connectors)
6x USB 2.0 ports (2 ports on the back panel, 4 ports available
through the internal USB connectors*)
ASMedia ASM1074 Chipset
4x USB 3.0 ports on the back panel
Renesas uPD720202 Chipset
2x USB 3.0 ports on the back panel
* Internal JUSB1 connector supports MSI Super Charger.
■
-
-
■
-
■
-
Audio
Realtek
®
ALC1150 Codec
7.1-Channel High Definition Audio
Supports S/PDIF Input
Supports S/PDIF output
■
-
-
-
LAN
1x Killer E2205 Gigabit LAN controller*
* The Killer Network Manager is only available for Windows 7 and Windows 8 currently. The
supported drivers for other operating systems would be available on the website if provided
by vendor.
■
