background image

Manual

Page 21

GC 590-40 GUNVALVE COMPONENT LOCATOR PARTS

LIST

Ref.

No.

Qty.

Part No.

Description

1

1

GC-765-14

Housing (Right) / Carcasa (Derecho)

2

1

8001660

Housing (Left) / Carcasa (Izquierdo)

3

1

GC-765-75

Trigger / Gatillo

4

1

GC-764-44

Pin / Pasador

5

1

8002258

Valve Body / Cuerpo de la Valvula

6*

1

GC-765-22

Trigger Cam / Leva de Gatillo

8*

1

GC-764-20

O-Ring / Empaque-O

9*

1

GC-764-18

Control Bolt / Tornillo de Control

10

1

8001661

Trigger Lock / Cerrojo del Gatillo

11

1

GC-764-41

Cap / Funda - Tapa

12*

1

GC-764-38

Valve Spring / Muelle de Válvula

13*

1

GC-764-36

Valve Ball / Válvula de Bola

14*

1

GC-764-32

Valve Seat / Asiento de la Válvula

15*

2

GC-764-30

O-Ring / Empaque-O

16

7

GC-765-16

Self-Tapping Screw / Tornillo de Rosca Cortante

17*

1

GC-765-30

Spring / Muelle

18

1

GC-765-53

Discharge Tube Assembly / Ensamblaje de Tubo de Descarga

19*

8000650

Inlet Tube / Tubo de Entrada

20*

1

8000168

Inlet Fitting / Conexión de Admisión

21

1

GC-764-50

Pin / Pasador

22

1

GC-765-54

Inlet Tube Assembly Includes: *19 & *20

Ensamblage de Tubo de Entrada

23

1

RK-775-75

Gunvalve Repair Kit Includes: *6, *8, *9, *12 - *15 & *17

Conjunto de Reparacion de Pistola Aerografica
