Side view, Bottom view – AT&T Generic 1 User Manual
Page 8
Program Button
Flash Button
Handset Jack
Handset
Data Jack
Adjunct (equipment)
Jack
Pause Button
Programmable
Dialing Buttons
Redial Button
Hold Light
Hold Button
Message Light
Dial Pad
TOP VIEW
Figure 3. 8102 Telephone, Top View
Adjunct
Power Jack
Line Jack
Tone Selector
(Slow/Fast)
SIDE VIEW
Ringer
Tone
Volume
Selector
Control
(Lo/Hi)
BOTTOM VIEW
Figure 4. 8102 Telephone, Side and Bottom Views
3
