AT&T Generic 1 User Manual
Page 7
Data jack
Handset
Flash button
Handset jack
Labeling
designation
card
Redial button
Hold light
Hold button
Message light
Dial pad
TOP VIEW
Figure 1. 8101 Telephone, Top View
Line jack
Positive disconnect
(Off/On)
Ringer
Mode
SIDE VIEW
volume
selector
control
(pulse/tone)
(Lo/Med/Hi)
BOTTOM VIEW
Figure 2. 8101 Telephone, Side and Bottom Views
2
