Flea
7
Getting Star
ted
Display Device(s) Satellite/Cable/DVD/PVR
or other source
Video Connections
The Flea accepts SD or HD analog video signals. 1 set of component input terminals and
1 S-Video input terminal are provided (cables are not supplied).
GREEN
BLUE
RED
GREEN BLUE RED GREEN BLUE RED
6)$%/
Y Pb Pr
6)$%/
Y Pb Pr
GREEN
BLUE
RED
). /54
6)$%/
). /54
3 3
3
• A signal received at the Flea component input in 480i or 576i, will go out from both
the component and S-Video outputs. A signal received at the S-Video input in 480i or
576i will go out from both the component and S-Video outputs.
component cable component cable
s-video cable s-video cable
component video 480i, 576i
s-video 480i, 576i
Both outputs are available
