Inhalt – WIKA DP-10 User Manual
Page 13
2333401 07/2009 GB/D/F/E
WIKA Betriebsanleitung Differenzdruckmessumformer
13
D
Inhalt
1.
Sicherheitshinweise
14
.
Messprinzip
14
3.
Montage
15
3.1
Montagehinweise
15
3.
Prozessanschlüsse
15
4.
Abmessungen in mm
16
5.
Elektrischer Anschluss
16
6.
Kalibrieranleitung
18
6.1
Einstellung des Nullpunktes (Z)
18
6.
Einstellung der Spanne (S)
18
6.3
Einstellung der Grenzkontakte
18
7.
Technische Daten
0
8.
EG-Konformitätserklärung
4
Inhalt
