FLOW CHART FOR SP-14 OPERATION
3.1. Correct Installation Order
Start
1 - Connect to display device
2 - Connect audio output
3 - Connect video input
6 - Connect power
7 - Configure display device
9 - Select free run output
format
MENU - Output
Settings/Output Format
10 – Make a choice on aspect
ratio treatment
MENU
– Output Settings/
ARC Mode
11 – Chose if the output shall
be frame synchronized
MENU
– Output Settings/
Lock Mode
Finished
8 - Select input channel
MENU
– Input Select
5 - Connect audio input
4 - Connect Genlock source
12 – Select the Genlock
Source
MENU
– Output Settings/
Reference Source
