6 technical specifications, Technical specifications, Table 2: technical specifications of the fc-322 – Kramer Electronics FC-322 User Manual
Page 10: 6technical specifications
KRAMER: SIMPLE CREATIVE TECHNOLOGY
Technical Specifications
8
6
Technical Specifications
The FC-322 technical specifications are shown in Table 2:
Table 2: Technical Specifications
INPUTS:
2 SD/HD-SDI, 3G HD-SDI on BNC connectors
OUTPUTS:
2 HDMI connectors
MAX DATA RATE:
Up to 3Gbps
STANDARD COMPLIANCE:
HDMI
INDICATOR LEDS:
SD/HD, OUT, ON
POWER SOURCE:
5V DC, 580mA
DIMENSIONS
12cm x 7.2cm x 2.4cm (4.7" x 2.8" x 1.0") W, D, H
WEIGHT:
0.3kg (0.7lbs)
ACCESSORIES:
Power supply
OPTIONS:
19” rack mount adapter
1 Specifications are subject to change without notice
