6

VM-73 - Connecting the VM-73

5

Connecting the VM-73

Always switch off the power to each device before connecting it to your
VM-73. After connecting your VM-73, connect its power and then

switch on the power to each device.

To connect the VM-73 as illustrated in the example in

Figure 2

:

1. Connect the HDMI input source (for example, a DVD player) to the HDMI

INPUT connector.

2. Connect the three HDMI OUT connectors to up to three HDMI acceptors, (for

example, LCD televisions with speakers).

Not all outputs need to be connected.

3. Connect a computer graphics input source (for example, a PC graphics card)

to the PC INPUT 15-pin HD connector.

4. Connect the three PC OUT 15-pin HD connectors to up to three PC

acceptors (for example, VGA displays or projectors).

5. Connect the component input source (for example, a DVD player) to the

COMP. INPUT RCA connectors (Y/Pb/Pr or Y/Cb/Cr).

6. Connect the three COMP. OUT connectors to up to three component

acceptors (for example, component displays or projectors).

7. Connect the Y/C input source (for example, a DVD player) to the Y/C INPUT

s-Video connector.

8. Connect the three Y/C OUT connectors to up to three Y/C acceptors (for

example, displays).

9. Connect the composite video input source (for example, a DVD player) to

the CV INPUT BNC connector.

10. Connect the three CV OUT connectors to up to three CV acceptors, (for

example, video recorders).
