Using Your Audio/Video DA

7

7

5.2 Configuring a 1:3 Audio/Video DA for Component (YUV) or RGB

To configure a 1:3 Audio/Video DA for component (YUV) or RGB by
combining three VM-30AV/B units, as illustrated in the example in Figure 4,
do the following.

Connect

1

the 1:3 Audio/Video DA for component (YUV) or RGB, as follows:

1. Connect the RGB source, by connecting:

 The‎R‎cable‎to‎the‎first‎unit’s‎INPUT‎connector
 The‎G‎cable‎to‎the‎second‎unit’s‎INPUT‎connector
 The‎B‎cable‎to‎the‎third‎unit’s‎INPUT‎connector

2. Connect the first RGB acceptor, by connecting the OUT 1 connector from the:

 First unit to the R cable
 Second unit to the G cable
 Third unit to the B cable

3. Connect the second RGB acceptor, by connecting the OUT 2 connector

2

from

the:
 First unit to the R cable
 Second unit to the G cable
 Third unit to the B cable

4. Connect the third RGB acceptor, by connecting the OUT 3 connector from the:

 First unit to the R cable
 Second unit to the G cable
 Third unit to the B cable

5. Connect the audio source and acceptors, as required.

6. On each VM-30AV/B unit, connect the 12V DC power adapter to the power

socket and connect the adapter to the mains electricity.

7. Adjust the audio level and the video EQ. and video level, as required, on the

front panel on the first VM-30AV/B unit.
This adjusts the levels on the combined 3 VM-30AV/B units.

1 Switch OFF the power on each device before connecting it to your VM-30AV/B units. After connecting your VM-30AV/B

units, switch on the power on each of the VM-30AV/B units and then switch on the power on each device

2 Not illustrated in Figure 4
