Technical Specifications
11
11
The default EDID is stored in the non-volatile memory when the READ
button no longer illuminates as well as the output LEDs.
7.2.3 Acquiring the Auto EDID
To acquire the Auto EDID, do the following:
1. Press the SELECT button several times until the OUTPUT LEDs flash in
sequence.
2. Press the READ button.
The READ button illuminates.
The auto EDID is stored in the non-volatile memory when the READ
button no longer illuminates as well as the output 1 LED.
8 Technical Specifications
Table 2 includes the technical specifications:
Table 2: Technical Specifications
1
INPUT:
of the VM-12HDCP 1:12 DVI Distributor
1 DVI, 1.2Vpp on a DVI Molex 24pin female connector; DDC signal 5Vpp (TTL)
OUTPUTS: 12 DVI, 1.2Vpp on DVI Molex 24pin female connectors; DDC signal 5Vpp
(TTL)
BANDWIDTH: 1.65Gbps
CONTROLS: SELECT and READ buttons for selecting and storing EDID information
POWER SOURCE: 100-240V AC, 50/60Hz, 11VA
DIMENSIONS: 19" x 7" x 1U (W, D, H) rack mountable
WEIGHT: 2.5 kg. (5.5 lbs.) approx.
ACCESSORIES: Power cord, rack "ears"
OPTIONS: Kramer DVI cables 2
1 Specifications are subject to change without notice
2 The complete list of Kramer cables is on our Web site at
http://www.kramerelectronics.com
