Acquiring EDID
10
7.1 The Simple Operation State
In the Simple operation state, the READ and SELECT front panel buttons
are disabled, and the default EDID is passed directly to the input.
To enter the Simple Operation State,
turn the machine ON while pressing the READ button.
The LEDS 3 and 4 flash three times
7.2 The Normal Operation State
In the Normal operation state, you can toggle between the following
working modes:
•
Sending the EDID from a selected output to the input (see section
7.2.1 )
• Sending the default EDID to the input (see section 7.2.2 )
• Sending the auto 1 EDID to the input (see section 7.2.3 )
To enter the Normal Operation State,
turn the machine ON while pressing the SELECT button.
LEDS 1 and 2 flash three times
7.2.1 Acquiring the EDID from a Selected Output
To select an EDID from a selected output, do the following:
1. Press the SELECT button, as required, to reach the desired output, which
flashes.
2. Press the READ button.
The EDID of the selected output is stored in the non-volatile memory when
the READ button no longer illuminates as well as the selected output LED.
7.2.2 Restoring the Default EDID
To restore the default EDID, do the following:
1. Press the SELECT button several times until the OUTPUT LEDs flash
simultaneously.
2. Press the READ button.
The READ button illuminates.
1 The auto EDID is an adjusted calculation of the EDIDs of all the connected outputs
