6 VM-100YC - Connecting the VM-100YC
4 Connecting the VM-100YC
Always switch off the power to each device before connecting it to your
VM-100YC. After connecting your VM-100YC, connect its power and
then switch on the power to each device.
To connect the VM-100YC as illustrated in the example in Figure 2 :
1. Connect the s-Video source (for example, an s-Video player) to the INPUT
4-pin connector.
2. Connect the OUT 4-pin connectors to up to 10 s-Video acceptors (for
example, s-Video recorders).
3. If required, connect the LOOP 4-pin connector, when looping units and
release the TERM switch on first unit (selecting Hi-Z). Push in the TERM
switch on the second unit (selecting 75

).
4. Connect the 12V DC power adapter to the power socket and connect the
adapter to the mains electricity (not shown in Figure 2 ).
5. Switch on the VM-100YC.
The s-Video source distributes to the s-Video acceptors.
