VM-100YC - Overview 5
# Feature Function
1 POWER Switch Illuminated switch for turning the unit ON or OFF
2 INPUT 4-pin Connector Connects to the s-Video source
3 LOOP 4-pin Connector For looping (if required) to increase the number of outputs
4 TERM Button Pushing in selects 75

; releasing selects Hi-Z (for looping
select Hi-Z)
5 OUT 4-pin Connector Connects to the s-Video acceptors (from 1 to 10)
6 12 VDC +12V DC connector for powering the unit
