KRAMER: SIMPLE CREATIVE TECHNOLOGY
Your VM-100CA
2
Has looping connectors that can be used to connect to a local monitor (or
some other component video acceptor), or to create larger systems 1
Features trimmers located on the underside that can be used to adjust the
component video Level and EQ. settings
In addition, the VM-100CA:
Accepts a digital audio (S/PDIF) input, loops it and distributes it to 10
digital audio (S/PDIF) outputs using RCA connectors
Accepts an unbalanced stereo audio input, loops it and distributes it to 10
unbalanced stereo audio outputs using RCA connectors
Features audio level control for the unbalanced stereo audio output
Is housed in a 19" 2U rack mountable enclosure, and is fed from a
100-264 VAC, 50/60 Hz, 18 VA power supply
To achieve the best performance:
Connect only good quality connection cables, thus avoiding interference,
deterioration in signal quality due to poor matching, and elevated noise levels
(often associated with low quality cables)
Avoid interference from neighboring electrical appliances that may
adversely influence signal quality and position your Kramer VM-100CA away
from moisture, excessive sunlight and dust
4 Your VM-100CA
Figure 1, Table 1, and Table 2 define the front and rear panels of the
VM-100CA 1:10 Video Component / Audio Distributor:
1 For example, you can connect two VM-100CA units to make a 1:20 video component / audio distributor (see section 6.2)
