Page 3

SERVICING PUMP

PUMP HEAD ADAPTER REPLACEMENT
To attach new adapter to pump head in case of damage to adapter

For Dual Head Peristaltics, the following:



Stop pump and disconnect power supply.



Press Release Lever and remove Pump Head Assembly from motor.



Unscrew and pivot three Quick Release screws and remove outside half of Pump Head.



Unscrew four (4) cap screws to remove old Male Adapter from inside Pump Head.



Attach new Male Adapter onto the shaft side of new Pump Head Assembly with four(4) cap screws.



Place one large key into the short

keyway of the

Shaft.



Align this key with keyway of hollow shaft in motor and press Pump Head assembly into motor. If

necessary rotate Rotor Assembly slightly until key and keyway align.



Press Release Lever and continue pressing Pump Head assembly into motor to close the gap between

two mating Adapters.



Remove pressure from Release Lever to allow spring pin to engage with Male Adapter. Rotate and pull on

Pump Head to ensure it is properly secured and will not pull off.



Ensure o-ring is on the shaft.



Install new hose and secure with outside Pump Head and three Quick Release Screws.



Pump Head Assembly is now ready for operation.

PUMP HEAD REPLACEMENT
For replacing a cracked or split plastic pump half, please see the instructions in the OMI #795-09456.

REPLACEMENT PARTS LIST

Description

Small Peristaltic
PPS-DV-DH

Large Peristaltic
PPL-DV-DH

Replacement Pump Head Only

401-35349-78

401-36347-78

Replacement Head Assembly

PPS-DH

PPL-DH

Replacement Head Assembly with Adapter

PPS-DHA

PPL-DHA

Motor

397-91472

Male Adapter (one/head)

539-39187-31

Female Adapter (two/motor)

539-39191-31

O-Ring replacement kit (12 pieces)

C-37515

C-37514

Hose 3/8” ID x 5/8” OD (50 ft)

729-90598-50

Hose 5/8” ID x 7/8” OD (50 ft)

729-90597-50

Ball Bearings (two/head)

760-09251

760-09256

Swivel Lock Fastener (three/head)

402-34971

Key

, 1/8” sq. x 9/16” long

758-08118-81 (two/head)

Key, 3/16” sq. x 7/8” long

758-09258 (one/head)

758-09258 (three/head)

Double Barb Fitting-

3/8” x 3/8”

730-09310

Double Barb Fitting-

5/8” x 5/8”

730-09309

Fuse 5.0 Amp(two/Remote Control)

780-91518

Boot Rubber for Toggle Switch

770-08481

Lever-Hand Release

623-39192-35

Retractable Pin

756-91475

Specifications May Change without Prior Notification
