DOCTER DOCTER®unipoint 3-12x56 - Manual (Page 11)

Technical data
Model
1
-4
x
2
4
1
.5
-6
x
4
2
2
,5
-1
0
x
5
0
3
-1
2
x
5
6
Enlargement
1x to
4x
1.5x to
6x
2.5x to
10x
3x to
12x
∅
Lens opening (mm) 24 42 50 56
Centre tube ∅ [mm] 30
Lens tube ∅ [mm] 30 48 56 62
Overall length [mm] 279 323 345 376
Mass [g] 1) 490 560 640 680
Ø Outlet pupil [mm]
15
6.0
15
7.0
15
4.9
15
4.7
Field of view at 100 metres
31.0 to
10.6
19.1 to
7.0
11.3 to
4.2
9.4 to
3.5
Parallax-free observation
distance [m]
100
Eye point [mm] >90
Set value of the height and side
settings [cm per 100m]
2.0 1.0 1.0 1.0
Overall adjustment range
in height and side
[cm per 100 m]
320 210 125 100
Eye error equalization
±
2.5
Function temperature range -25°C to +40°C
Storage temperature range -40°C to +55°C
Watertightness Watertight 1 m
With Z-rail additional 20g heavier
