Parts List
No.
Description
Qty
1
Exhaust valve cover
1
2
Hex bolt M5x22
6
3
Spring washer
6
4
Seal
4
5
Air Cap
1
6
Seal
1
7
Inner lining
1
8
O-ring
1
9
Spring
1
10
Gasket
1
11
O-ring
1
12
Head valve piston
1
13
O-ring
1
14
O-ring
1
15
O-ring
1
16
Collar
1
17
O-ring
1
18
Driver blade unit
1
19
Filter
1
20
O-ring
1
21
Lining ring
1
22
O-ring
1
23
Cylinder
1
24
Gasket
1
25
Bumper
1
26
Body
1
27
Nozzle
1
28
Switch unit
1
29
Trigger plate
1
30
Spring pin
1
31
O-ring
1
32
Trigger
1
33
Pin
1
34
Safety guide
1
35
Spring pin
2
No.
Description
Qty
36
Safety
1
37
Non-marking tip
1
38
Spacer
1
39
Spring set
1
40
Spring
1
41
Seal
9
42
Hex bolt M4x8
3
43
Safety cover
1
44
Driver guide cover
1
45
Hex bolt
2
46
Driver guide
1
47
Magazine A
1
48
Steel bar
1
49
Spring
2
50
Pusher unit
2
51
Pusher holder
1
52
O-ring
1
53
Nut
1
54
Tail cover
1
55
Cylinder pin
1
56
Hex bolt M4x12
1
57
Pin
1
58
Click lever
1
59
Spring
1
60
Magazine B
1
61
Hex bolt M4x35
2
62
Tail hanger
1
63
Hex bolt M4x8
2
64
Nut M5
1
65
Hex bolt M5x18
1
66
O-ring
1
67
End cap
1
68
Air plug
1
69
Hand grip
1
