AIR CONDITIONER FEATURES
The controls featured in this manual are representative
of many available models. Your model may offer slightly
different features.
Cool Mode
The desired cool setting is selected by rotating the knob to the
right to the appropriate location.
HI COOL has maximum cooling effect and airflow.
LO COOL has minimum cooling effect and airflow.
Fan Mode
Rotate the knob to the left to select your choice of fan speeds for air
circulation.
NOTE: When selecting a fan speed, the compressor will not run.
Thermostat
The thermostat is used to set the desired room temperature when the
unit is being operated in the COOL MODE.
TEMPERATURE
min
cool
max
cool
COOLING
1
4
5
6
7
To set the desired room temperature, rotate the thermostat switch
to the desired setting. After the set temperature is achieved the
thermostat will automatically start and stop the compressor in order
to maintain the desired set temperature.
Rotate the thermostat selector clockwise for higher cool settings.
Higher cool settings will provide lower room temperature. Rotate
the thermostat selector counter clockwise for lower cool settings.
Lower cool settings will provide higher room temperature.
2
3
lo
fan
lo
cool
hi
cool
hi
fan
OFF
Air Directional Louvers
The louvers will allow you to direct the air flow
Left or Right throughout the room as needed.
Move the Center handle from side to side until the
desired Left/Right direction is obtained.
Center handle
Air Direction
Please always wait 3 minutes when turning unit off then on again, and when changing
from cool to fan and back to cool. This prevents compressor from overheating & possible
circuit breaker tripping.
Center handles
NOTE: The Air directional louvers and the Center
handles would be slightly different. It depends on
the models.
Please always wait 3 minutes when turning the unit off then on again, and when changing
from cool to fan and back to cool. This prevents compressor from overheating and the circuit
breaker from possibly tripping.
NOTE: The air directional louvers and the center
handles may be slightly different depending on the
model type.
The desired cool setting is selected by rotating the cooling
knob to the right to the appropriate location.
The thermostat is used to set the desired room temperature when
the unit is being operated in the “ COOL MODE.”
To set the desired room temperature, rotate the cooling thermostat
knob to the desired setting. After the set temperature is achieved the
thermostat will automatically start and stop the compressor in order
to maintain the desired set temperature.
