XDS8 XDS10 XDS12
Impedance (Nominal) 8 Ohms 8 Ohms 8 Ohms
Power (Continuous) 100 Watts 250 Watts 300 Watts
Sensitivty (1 W / 1 M) 92 dB 94 dB 96 dB
Calculated Max SPL 112 dB 118 dB 121 dB
Dispersion (-6 dB Points) (H x V) 100º x 100º 50-100º x 50º 80º x 50º
non-rotatable rotatable rotatable
Frequency Response (-3dB) 80 Hz - 20 kHz 55 Hz - 20 kHz 50 Hz - 18 kHz
Frequency Response (-10dB) 70 Hz - 20 kHz 50 Hz - 20 kHz 45 Hz - 20 kHz
Connection 4 pole twist lock connectors (x2) 4 pole twist lock connectors (x2) 4 pole twist lock connectors (x2)
screw terminal strip (x2) screw terminal strip (x2) screw terminal strip (x2)
Components 1 x 8” Woofer, 1 x 10” Woofer, 1 x 12” Woofer,
1 x 1.35” HF Driver 1 x 1.35” HF Driver 1 x 1.7” HF Driver
Net Dimensions (w x d x h) 293 mm x 284 mm x 408 mm 348.6 mm x 328 mm x 502 mm 396 mm x 396.4 mm x 620 mm
(11.5” x 11.2” x 16.1”) (13.7” x 12.9” x 19.8”) (15.6” x 15.6” x 24.4”)
Shipping Dimensions (w x d x h) 350mm x 350 mm x 470 mm 430 mm x 410 mm x 605 mm 480 mm x 480 mm x 720 mm
(13.8” x 13.8” x 18.5”) (16.9” x 16.1” x 23.8”) (18.9” x 18.9” x 28.3”)
Net Weight 10 kg 16.5 kg 20 kg
22.0 (lbs) 36.3 (lbs) 44.0 (lbs)
Shipping Weight 11.5 kg 18.5 kg 23 kg
25.3 (lbs) 40.7 (lbs) 50.6 (lbs)
XDS115 XDS212
Impedance (Nominal) 8 Ohms 8 Ohms
Power (Continuous) 300 Watts 600 Watts
Sensitivity (1W / 1M) 96 dB 99 dB
Calculated Max SPL 121 dB 127 dB
Frequency Response (-3dB) 35 Hz - 500 Hz 50 Hz - 180 Hz
Frequency Response (-10dB) 30 Hz - 500 Hz 45 Hz - 180 Hz
Connection 4 pole twist lock connectors (x2) 4 pole twist lock connectors (x2)
Components 1 x 15” Woofer 2 x 12” Woofers
Net Dimensions (w x d x h) 512 mm x 600 mm x 650 mm 512 mm x 600 mm x 680 mm
(20.1” x 23.6” x 25.6”) (20.1” x 23.6” x 26.8”)
Shipping Dimensions (w x d x h) 700 mm x 615 mm x 750 mm 700 mm x 615 mm x 780 mm
(27.6” x 24.2” x 29.5”) (27.6” x 24.2” x 30.7”)
Net Weight 30 kg 40 kg
66.0 (lbs) 88.0 (lbs)
Shipping Weight 35 kg 45 kg
77.0 (lbs) 99.0 (lbs)
PAGE 11 XDS SERIES INSTALLATION AND OPERATION MANUAL
SPECIFICATIONS
