R E A R PA N E L
PAG E 5 VG A 1 4 I N S TA L L AT I O N & O P E R AT I O N M A N UA L
VIDEO INPUT CONNECTOR
One video source input is provided, featuring:
• One VGA video input on a single 15 pin
high density D connector
VIDEO OUTPUT CONNECTORS
Four video outputs are provided, each featuring:
• One VGA video output on a single 15 pin
high density D connector
DC POWER INLET
The VGA14 switcher is fitted with a DC power plug-pack
input connector. Please ensure that the plug-pack used is of
an approved type and is of sufficient current carrying capacity
with the correct voltage and connector polarity
1 2 3 4
OUTPUTS INPUT
1
2
3
2 1 3
