A&D 191 User Manual

Page 19

YES -

voltage will be in a low state until the
unit is busy then voltage level goes high.

NO -

voltage will be in a high state until the
unit is busy then voltage level goes low.

ONLINE/OFFLINE

ONLINE/OFFLINE is next.
Choices:

YES -

enables the rocker switch to turn the
printer offline.

NO -

disables the ONLINE/OFFLINE ability.

EXT CH SET

EXT CH SET is next. This stands for Extended Character Set.
Choices:

YES -

Allows you to use hexidecimal numbers
above 80 (true only for 8 data bits.)

NO -

Disables the Extended Character Set
ability.

PRINT READY

PRINT READY is next.
Choices:

YES -

Prints R

Ready

eady

eady upon power up.

NO -

Disables printing Ready

Ready

WARNING -

ARNING -

ARNING - If you choose NO

NO, then you will need to hold

the left side of the rocker switch down for 4 to 6 seconds
to access the setup menu. Begin timing when you plug in
power to the unit and the red light comes on. The paper
feed motor does not run upon power up when Ready

Ready

Ready is

disabled.

The next item in the Setup Menu is SET CL

SET CL

SET CLOCK

OCK

With the printer in the setup menu and with SET CL

SET CL

SET CLOCK

OCK

OCK as

the last item printed, if you press OK

OK (right side) the printer

will print the following:

The printout shows the year currently in memory. The 00000 is

reversed (white on black) to show the position of the cursor.
This is the number which will be incremented if NEXT

NEXT

NEXT (left

side) is pressed. If the number is correct press OK

OK (right side)

and the following is printed:

Ext Ch Set

The choice to use the
extended character
set is available only
when 8 data bits are
chosen.

PPPPPrint Ready

rint Ready

SET CL

SET CLOCK

OCK

Online/Offline
