Timer Operating Instructions
Replacement Timer
New Timer
General Specifications
Installation
Product Line: Wildgame Innovations
Model#: XA
Analog Timer Unit
Daily Feed Times: 24
Run Time Duration:
Programmable from 1 to 20 seconds per feeding
Remove old timer by disconnection the motor lead
wires from the motor terminals and the power supply
wires (typically red and black in color) from the battery
terminals.
Now proceed to “New Timer” installation instructions
Connect Motor Wires:
Connect the White and Blue wires from the timer unit to
the terminals on the motor. The order of which wire to
which terminal does not matter as the motor will turn in
a circle no matter the order.
