PARTS LIST
28
JC IOM 5/08
TYPICAL
Item QTY/Pump Part Name Alternate Part Name
100 1
Casing
100B
1
Suction Liner Suction Disc Liner
101 1(2)
Impeller
105
1 Lantern Ring Seal Cage
106 5
Packing Ring
107 1
Gland
112C 1
Thrust Bearing
119B 1
End Cover Bearing Retainer
122 1
Shaft
123C
Deflector Slinger
126 1(2)
Shaft Sleeve
®
134A 1
Bearing Housing
136 1
Locknut
168C 1
Radial Bearing
182 1
Suction Cover Suction Disc
184 1
Stuffing Box Cover Hub Disc
193B 2
Grease Fitting
222 1
Set Screw
228 1
Bearing Frame
332 3
Grease Seal
351 1(1)
Gasket
353 2
Stud, Gland
355 2
Hex Nut
356A 2
Stud
361 1
Snap Ring
370C 4
H Cap Screw
370E 8
H Cap Screw
370J 8
H Cap Screw
382 1
Lockwasher
400 1
Key
408 1
Pipe Plug
412F 1
O-Ring
415 4
Hex Jam Nut
496 1
O-Ring
528J 2
Washer, 353
528K 8
Washer, 370E
528L 8
Washer, 370j
528P 4
Washer, 356A
NOTES:
(1) Buna-N O-Ring 496A replaces gasket 351 on sizes 6x6-14 and 8x10-18.
(2) Sleeve 126 is sealed to impeller 101 with RTV silicone. All Sizes Except 10x12-22 Grease Lube Bearings.
