Item
number
Part
name
Pump
size
Part number Thread
size
Type Hex size Torque
value
370H Screw,
cover to
adapter
24 x 24-27 A02818A149 M20 x 2.5 Hex head
capscrew
30 mm 22 (30)
20 x 24-29
20 x 24-31
24 x 30-35
30 x 30-41 A02818A148
370K Screw, end
cover to
frame
XL1 A03723A92 M12 x 1.75 Socket
head
capscrew
Internal 10
mm
24 (33)
XL2-S and
XL2
A03723A93
372T Screw,
button
head
XL1, XL2-
S, and XL2
A09270A209 ¼ - 28 Button
head
socket cap
screw
5/32 6 (8)
418 Jackbolt,
cover to
adapter
24 x 24-27 A02818A149 M20 x 2.5 Hex head
capscrew
30 mm 22 (30)
20 x 24-29
20 x 24-31 A02818A151
24 x 30-35 A02818A148
30 x 30-41
3181 and 3186 torque values in ft-lb (Nm)
Item
number
Part name Pump
size
Part number Thread
size
Type Hex size Torque
value
— Screw,
coupling
guard
All A02818A-89 M10 x 1.5 Hex head
capscrew
17 mm 10 (15)
— Nut,
coupling
guard
All A02089A-10 M10 x 1.5 Hex nut 17 mm —
370A Screw,
stuffing
box to
casing
14 in. A02818A-163 M24 x 3.0 Hex head
capscrew
36 mm 600 (800)
16 in. A02818A-145 M20 x 2.5 30 mm 375 (500)
19 in. A02818A-145 M20 x 2.5 30 mm 375 (500)
22 in. A02818A-165 M24 x 3.0 36 mm 600 (800)
— Screw,
casing foot
to
baseplate
S and M A02818A-146 M20 x 2.5 Hex head
capscrew
30 mm 125 (170)
L and XL A02818A-148 M20 x 2.5 30 mm 125 (170)
14 x 16-22 A02818A-165 M24 x 3.0 36 mm 200 (270)
A02817A-112
— Screw,
frame foot
to
baseplate
S-group A02818A-105 M12 x 1.75 Hex head
capscrew
19 mm 30 (40)
M-group A02818A-126 M16 x 2.0 24 mm 50 (65)
L and XL A02818A-145 M 20 x 2.5 30 mm 80 (110)
356E Stud,
sideplate
to casing
14 in. to
16 in.
A02815A-37 M10 x 1.5 Stud N/A —
19 in. to
22 in.
A02815A-38 M12 x 1.75 —
357A Cap nut,
sideplate
to casing
14 in. to
16 in.
A06245A M10 x 1.5 Hex nut 22.2 mm 10 (15)
19 in. to
22 in.
A06245A M12 x 1.75 25.4 mm 20 (25)
