4.0 TECHNICAL DATA
4.1 Technical Specification
Specifications has been mentioned on provided catlog or sales drawing with the product.
Table 1. Product Specifications
Specifications:
Regular Hydraulic Regulator 20517
Supply /Inlet Pressure
3,000 psi (207bar)
3,000 psi (207bar)
5,000 psi (345 bar)
Regulated Pressure Range:
Manual
High Sensitivity
200 ‐ 1600 psi (14 ‐110 bar)
300 ‐ 1600 PSI (21 ‐110 bar)
500 ‐ 1600 PSI (34 ‐110 bar)
Full Range
350 ‐ 2800 psi (24‐193 bar)
300 ‐ 2800 PSI (21 ‐ 193 bar)
500 ‐ 3000 PSI (34 ‐ 207 bar)
“F” Prefix Pneumatic failsafe motor:
High Sensitivity
200 ‐ 1600 psi (14 ‐110 bar)
300 ‐ 1600 PSI (21 ‐110 bar)
500 ‐ 1600 PSI (34 ‐110 bar)
Full Range
350 ‐ 2800 psi (24‐193 bar)
300 ‐ 2800 PSI (21 ‐ 193 bar)
500 ‐ 3000 PSI (34 ‐ 207 bar)
“G” Prefix Hydraulic failsafe motor:
High Sensitivity
200 ‐ 1600 psi (14 ‐110 bar)
300 ‐ 1600 PSI (21 ‐110 bar)
500 ‐ 1600 PSI (34 ‐110 bar)
Full Range
350 ‐ 2800 psi (24‐193 bar)
300 ‐ 2800 PSI (21 ‐ 193 bar)
500 ‐ 3000 PSI (34 ‐ 207 bar)
Fluid Temperature Range:
‐40° to +250°F (‐40° to +121°C)
Proof Pressure:
4,500 PSI (310 bar)
4,500 PSI (310 bar)
7,500 PSI (517 bar)
Flow:
Flow Rate:
120 GPM (@ 50 ft/s)
Cv Inlet:
17.5
Cv Vent:
1.6
Porting:
Inlet 1:
1” NPT Standard, SAE Optional
Inlet 2:
1” NPT Standard, SAE Optional
Outlet (regulated):
1‐1/2” NPT Standard, SAE Optional
Vent:
1” NPT Standard, SAE Optional
Materials of Construction:
Body:
Phosphate coated alloy steel (std.)
Option: Stainless steel
Flanges:
Phosphate coated alloy steel (std.)
Option: Stainless steel
Spring Tower:
Manual
Phosphate coated alloy steel (std.) /SS
Pneumatic Motor model
Painted alloy steel (std.) /SS
Hydraulic Motor model
Painted alloy steel (std.) /SS
Socket Head Screws:
Stainless Steel (std.)
Standard O’ring Material:
Buna N
Wetted Parts:
Stainless steel & Bronze
Pneumatic Pilot Motor ("F" Prefix)
Pilot Motor Working Pressure:
80 ‐ 120 PSI (5.5 ‐ 8.3 bar)
Porting:
1/4” NPT
Operating Temperature Range:
32° to +250°F (0° to +120°C)
Hydraulic Pilot Motor (“G” prefi x):
Pilot Motor Working Pressure:
400 ‐ 1600 PSI (27.6 ‐ 110.3 bar)
Porting:
SAE for 3/8” Tube (Size ‐6)
Operating Temperature Range:
‐40° to +250°F (‐40° to +121°C)
Approximate Shipping Weight:
Manual:
67 lbs. (30.4 kg)
Pneumatic & Hydraulic Motor
90 lbs. (40.8 kg)
70 lbs. (31.8 kg)
90 lbs. (40.8 kg) Both
‐30° to +185°F (‐34° to +85°C)
400 ‐ 1600 PSI (27.6 ‐ 110.3 bar)
SAE for 3/8” Tube (Size ‐6)
‐30° to +185°F (‐34° to +85°C)
1/4” NPT
Phosphate coated Carbon Steel
Phosphate coated Carbon Steel
Phosphate coated Carbon Steel
Zinc plated alloy steel
Buna N
400 series Stainless Steel
80 ‐ 120 PSI (5.5 ‐ 8.3 bar)
Land Regulator L20517
‐30° to +185°F (‐34° to +85°C)
120 GPM (@ 50 ft/s)
17.5
1.6 (18 GPM @ 50 ft/s)
1” NPT Standard, SAE Optional
1” NPT Standard, SAE Optional
1‐1/2” NPT Standard, SAE Optional
1” NPT Standard, SAE Optional
Phosphate coated Ductile Iron
Phosphate coated Carbon Steel
