REMEMBER to turn off the power.Follow the steps below to hang your fan
properly:
Step 1. Secure the hanger bracket to the ceiling outlet box using screws
included with your outlet box, lock washers included with the fan.(Fig 5)
Step 2. Loosen the two set screws and remove the hitch pin and lock pin
from the top coupling of the motor assembly.(Fig 6)
Step 3. Remove hanger ball from downrod assembly by loosening set
screw,removing the cross pin,and sliding ball off rod.(Fig 7)
Step 4. Carefully feed fan wires up through the downrod (Fig 8).
Thread the rod into the coupling, line up holes and replace lock pin and
hitch pin.Tighten set screws.
Step 5. Slip coupling cover, and canopy onto downrod (Fig 8). Carefully
reinstall hanger ball onto rod being sure that cross pin is in the correct
position,set screws are tighten and wires are not twisted.
Step 6. Place downrod rubber cover onto the hanger ball (Fig 9)
Step 7. Now lift motor assembly into position and place hanger ball
into hanger bracket.Rotate until the check groove has dropped into the
registration slot and seats firmly. (Fig 10) Rod should not rotate if this
is done correctly.
HANGING THE FAN
4
WARNING: All of the parts, hardware and components such as the hanger
bracket and hanger ball have been provided for your safety and the proper
installation of your new ceiling fan. The use of other parts, hardware or
components not supplied by Minka Aire
® with the fan will void the Minka
Aire ® Warranty.
