BLADE INSTALLATION
Align and engage the top holes from one of the blades to the upper blade holder tabs.
Carefully align the bottom holes from the blade to the holes from the lower blade holder.
Secure blade with 3 screws and metal washers provided. Follow the same process for the
remaining two blades. (Fig. 14)
Blade
Fig. 14
Screw
Fan motor
Metal washer
Upper blade
holder tabs
Lower blade
holder
