Attaching the switch cup – Minka Group F588-SP-BN User Manual
Page 18
Fig. 18
9
Remove the screws from the switch cup plate. Slide switch cup up against plate and rotate it until the
screw holes are aligned. Secure switch cup to plate using the screws removed earlier. (Fig. 18)
NOTE: DO NOT PINCH WIRES BETWEEN THE SWITCH HOUSING AND THE SWITCH CUP PLATE.
ATTACHING THE SWITCH CUP
SWITCH CUP
SWITCH CUP
PLATE
SCREWS
