4 5
ACCESSORIES
STANDARD SOLUTIONS FOR CALIBRATION:
The ULTRAPEN™ PT4 requires pH 4, pH 7, and pH 10 pH Buffer Solutions and
80mV Quinhydrone, 260mV Quinhydrone, or 470mV MLC Light’s ORP Standard
Solutions for wet calibration, and Sensor Storage Solution for proper storage.
Order Model Numbers: PH4Q, PH7Q, PH10Q, ORP802OZ, ORP2602OZ,
ORP4701OZ, ORPCALKIT, SSQ.
RPT4 Replacement FC E Sensor (with instructions)
OECP-25/-100 ORP Electrode Cleaning Paper, QTY 25 or QTY 100
For additional calibration kits available, contact the Myron L Company.
MYRON L WARRANTY
The PT4, excluding the FC E sensor, has a one (1) year limited warranty.
The FC E sensor has a six (6) month limited warranty.
PT4OM 08-13B
SpECIFICATIONS
FC E Temperature
Range: 0 – 10.0 ppm 0 - 71°C / 32 - 160°F
Accuracy: <5.00ppm ±0.3 ppm
≥5.00ppm ±0.5 ppm
± 0.1ºC / ± 0.1ºF
Resolution: 0.01 ppm 0.1ºC / 0.1ºF
Time to Reading Stabilization: 10 - 45 seconds
Power Consumption: Active Mode 37mA, Sleep Mode 2μA
Temperature Compensation: Automatic In Calibration Mode From 15ºC to 30ºC
Physical Dimensions: 17.15cm L x 1.59cm D / 6.75in. L x 0.625in. D
Weight: 50.4g / 1.78oz. (without soaker cap and lanyard)
Case Material: Anodized Aircraft Aluminum with Protective Coating
Battery Type: N type, Alkaline, 1.5V
Calibration Standard Solutions: pH4, pH7, pH10, ORP80, ORP260, ORP470
Operating/Storage Temperature: 0 - 55ºC / 32 - 131ºF
Enclosure Ratings: IP67 and NEMA6
EN61236-1: 2006 – Annex A: 2008: Electrostatic discharge to the PT4 may
cause it to spontaneously turn on. If this occurs, the PT4 will turn off.
QUICK REFERENCE INSTRUCTIONS
1. Push and release the push button to turn the PT4 on.
2. While the LED flashes rapidly, dip the PT4 in sample solution so that the sensor
is completely submerged.
3. While LED flashes slowly, swirl PT4 around to remove bubbles, keeping
the sensor submerged. Avoid contact with sides/bottom of container, if
applicable.
If in LIVE mode, while the LED is flashing slowly, the display will alternate between
the live FC E and temperature readings. Note readings for your records.
If in Hold mode, when the LED is flashing slowly, the display will alternate between
the live FC E and temperature readings, when the LED turns on solid, remove
the PT4 from the solution. The display will alternate between the captured FC E
and temperature readings. Note readings for your records.
IV. FC E Sensor Replacement
CAUTION: Only Remove/Replace the FC E sensor in a CLEAN and DRY
environment!
To remove the FC E sensor: Remove the soaker cap; make sure the PT4 (including
the FC E sensor) is clean and dry.
Loosen the battery tray (to allow pressure equalization).
Then firmly grasp the FC E sensor body and slowly pull the FC E sensor out.
To install a new FC E sensor: Line up the alignment tabs on the FC E sensor with
the alignment slots on the PT4 unit. Gently push the FC E sensor into position, then
close the battery cap.
MYRON L COMPANY
2450 Impala Drive
Carlsbad, Ca 92010-7226
Phone: +1-760-438-2021
Customer Service E-Mail: [email protected]
Technical Support E-Mail: [email protected]
Website: www.myronl.com
MADE IN USA ©2012 MYRON L COMPANY
