LoadMaster for HP ProLiant
Installation Guide
Figure 2-7: Temporary license warning
Click the OK button.
Figure 2-8: Appliance Vitals screen
The Appliance Vitals screen of the LoadMaster should appear.
In the main menu, select System Configuration.
Select the eth0 menu option within the Interfaces section.
Figure 2-9: Network Interface screen
In the Network Interface 0 screen, enter the IP address of the eth0 interface (the
network-facing interface of the LoadMaster) in the Interface Address input field.
Click the Set Address button.
Click the eth1 menu option within the Interfaces section.
In the Network Interface 1 screen, enter the IP address of the eth1 interface (the farm-
side interface of the LoadMaster) in the Interface Address input field.
Click the Set Address button.
This interface is optional, depending on the network configuration.
