DMXPathfinder LR
Installation & Assembly
8
I/O C
ABLE
C
ONNECTION
Strip back about 3 inches (8cm) of cable jacket and braid shield from each input
or output cable. Apply a 2.5" (6.5cm) piece of 1/16" heat shrink to the drain wire
and a 1" (2.5cm) piece of 3/8" heat shrink over the exposed braid ends where
each cable was stripped. These precautions are to ensure that cable shields
cannot contact each other or equipment ground.
Strip about 1/2" of insulation from the four signal wires in each cable.
Bend over 1/4" of the exposed conductors on all five wires and connect them to
the terminal block. Note that each five-position terminal block is numbered 1
thru 5 on the termination board. This corresponds to the pin numbering on XLR
5-pin connectors, that is:
INTER-MODULE BUS
