Operating press. continuously adj. 30-95 bar / 3 - 9,5 MPa / 1400 psi
Nozzle size
042
Permissible overpressure 120 bar / 12 MPa / 1600 psi
Water output bei 1.700 U/min 8.3 l/min / 2.1 Gpm
Water inlet pressure 10 bar / 1,0 MPa / 145 psi
Water inlet temperature max. 60 °C / 140 °F
Hose drum yes
Steel-weave high-pressure hose 15 m, NW 6
Detergent suction yes
Total stop system yes
Connected load 110-127 V~, 14,0 A, 60 Hz
Power input P 1 - 1.65 kW
Power output P 2 - 1.35 kW
Weight 31,5 kg
Dim. incl. pulling handle in mm 360 x 365 x 870
Sound level acc. to DIN 45 635 88 dB (A)
Sound level with Dirtkiller 90 dB (A)
Acoustic power LWA 93 dB (A)
Recoil at lance ca. 27 N
Vibration at lance 1,9 m/s 2
Zulässige Abweichung der Zahlenwerte ± 5 % nach VDMA Einheitsblatt 24411
Kränzle 1122 TS T
Technical data 4
