! Frequency Band, Group & Channel and
Frequency are factory pre-set, thus, its
parameter values are displayed after it is ACT
synced. Values cannot be changed.
( ) Frequency Band
( ) Group and Channel
( ) Frequency
Setting Input Sensitivity Level
! 4 Selectable Sensitivity Levels:
LINE、
MIC-L (MICROPHONE-LOW)、
MIC-M (MICROPHONE- MID)、
MIC-H (MICROPHONE-HIGH).
! Press MODE button until mode
appears.
! Press SET button once to activate function.
! Press SET button to select the desired
sensitivity level.
! Press MODE button to confirm and save the
change.
! The higher the sensitivity level, the lower the
dynamic range of input signals. Meanwhile noise
will increase, and the feedback problem will be
getting more serious.
NOTE: Guitar setting is recommended at LINE
level.
AF GAIN
8A
BAND
07 03
CH GRP
802.000
MHz
FREQUENCY
6 7
Bodypack Transmitter Bodypack Transmitter
MIC-H
AF GAIN
MIC-L
AF GAIN
LINE
AF GAIN
MIC-M
AF GAIN
SET SET
SET
SET
