 LCD Screen
 Parameters Screen
 AF (audio) MUTE
 Transmitter Battery Meter
LCD Display Screen
16
Fully Lit LCD Display
6 7
! When power is off, reverse-installation of
protection cover will turn on the switch
automatically. To turn off the system, remove
the cover to turn off.
!
operation for full protection.
!
Color-coded channel identification clip can be
attached to the bottom of protection cover.
Protection cover must be attached during
MP-80 Charger charges both transmitters and
18500 rechargeable batteries.
MP-80 Battery Charger (Optional)
18500 Charging Transmitters Charging
0 1 0 2
GRP CH
A4
A1
A2
A3
A1
15 A2
A3
A4
