23

SLAVE CYLINDER CONFIGURATION

(1)First the T-WREX should be FULLY extended using the manual control lever on the center section

of the arm, under the cover.

(2)Next, remove the rear cover to expose the lift cylinder and the slave cylinder.

(3)Turn both the HPU and e-stop off. On the extension cylinders, remove the -8 caps on the tee fittings

and connect jumper hoses between left and right cylinders, both in the front and rear sections of the

arm.

(4)Turn HPU back on. Raise the tool high enough that the front section can not hit the floor using the

manual control lever on the center section of the arm.

(5)Again using manual control on the arm, fully extend and retract the tool several times (six to ten).

Leave the tool in the fully extended position and lower it fully.

(6)Turn off the HPU again. Disconnect hoses from lift cylinder, marking them as to which fitting they

connect to.

(7)Using -8 to -6 adapters on the slave cylinder, connect lift hoses to tee fittings on the slave cylinder.

(8)Using manual controls again, actuate the raise and lower valve, repeatedly (6 to10) times, being care-

ful to fully extend and retract the slave cylinder each time, but not holding the control long enough to

cause the arm to begin to retract.

(9)Leave the slave cylinder in the retracted position (opposite the extension cylinders, which should be

fully extended at this point).

(10)Turn the HPU off. Being careful to minimize oil loss and air intrusion, remove jumper hoses one at

a time and cap tee fittings.

(11)Remove lift hoses from slave one at a time and cap, to minimize air intrusion, and then reconnect

lift hoses to the lift cylinder on the appropriate fittings.

(12)Turn HPU and e-stop back on and verify that the extend and retract functions actuate smooth and

level from the control console. Replace top and rear covers.
