Technical Data
Beijer Electronics, MAEN810C
13
3
Technical Data
Parameter
EXTER K30m
Front panel,
W x H x D
202 x 187 x 6 mm
Mounting
depth
57 mm (157 mm including clearance)
Front panel
seal
IP 66
Rear panel
seal
IP 20
Keyboard
material
Membrane switch keyboard with metal domes. Overlay film of Autotex
F157 * with print on reverse side. 1 million operations.
Reverse side
material
Powder-coated aluminum
Weight
0.95 kg
Serial port
RS422/RS485
25-pin D-sub contact, chassis-mounted female with
standard locking screws 4-40 UNC.
Serial port
RS232C
9-pin D-sub contact, male with standard locking screws 4-40 UNC.
Ethernet
Shielded RJ 45
USB
Host type A (USB 1.1), max output current 500 mA
Flash
memory for
application
12 MB (incl. fonts)
Real time
clock
±20 PPM + error because of ambient temperature and supply voltage.
Total maximum error: 1 min/month at 25
°
C
Temperature coefficient: 0.004 ppm/
°
C
2
Real time
clock
battery
CR2450 (UL and cUL: Sanyo or Panasonic)
Minimum lifetime: 3 years
Power
consumption
at rated
voltage
Normal: 0.15 A
Maximum: 0.35 A
Display
FSTN-LCD. 240 x 64 pixels, monocrome transflective.
LED backlight lifetime at the ambient temperature of
+25
°
C: >35,000 h.
Active area
of display,
W x H
127.0 x 33.8 mm
Fuse
Internal DC fuse, 2.0 AT, 5 x 20 mm
Power supply +24V DC (20 - 30V DC). Power supply connector.
CE: The power supply must conform with the requirements according
to IEC 60950 and IEC 61558-2-4.
UL and cUL: The power supply must conform with the requirements for
class II power supplies.
Ambient
temperature
Vertical installation: 0
°
to +50
°
C
Horizontal installation: 0
°
to +40
°
C
Storage
temperature
-20
°
to +70
°
C
Relative
humidity
5 - 85 % non-condensed
CE approvals Noise tested according to EN61000-6-3 emission and EN61000-6-2
immunity.
