Technical Data
Beijer Electronics, MAEN809D 13
3 Technical Data
Parameter EXTER T60c EXTER T60m EXTER T60
EXTER T60m of
hardware
version type no
07600 or higher
Front panel,
W x H x D 202 x 152 x 6 mm
Mounting
depth 57 mm (157 mm including clearance)
Front panel
seal IP 66
Rear panel
seal IP 20
Touch screen
material Touch screen: Polyester on glass, 1 million finger touch operations.
Overlay: Autotex F157/F207 *.
Reverse side
material Powder-coated aluminum
Weight 0.9 kg
Serial port
RS422/RS485 25-pin D-sub contact, chassis-mounted female with standard locking screws
4-40 UNC.
Serial port
RS232C 9-pin D-sub contact, male with standard locking screws 4-40 UNC.
Ethernet Shielded RJ 45
USB Host type A (USB 1.1), max output current 500 mA
Flash memory
for
application 12 MB (incl. fonts)
Real time
clock ±20 PPM + error because of ambient temperature and supply voltage.
Total maximum error: 1 min/month at 25
°C
Temperature coefficient: -0.034±0.006 ppm/°C 2
Real time
clock battery CR2450 (UL and cUL: Sanyo or Panasonic)
Minimum lifetime: 3 years
Power
consumption
at rated
voltage Normal: 0.25 A
Maximum: 0.45 A Normal: 0.2 A
Maximum: 0.4 A
Display Transmissive
color STN-LCD.
320 x 240 pixels,
64K colors. Transmissive
monochrome
STN-LCD.
320 x 240 pixels. TFT-LCD.
320 x 240 pixels,
64K colors. TFT-LCD.
320 x 240 pixels,
16 greyscales.
CCFL backlight
lifetime at the
ambient
temperature of
+25
°C:
>75,000 h.
CCFL backlight
lifetime at the
ambient
temperature of
+25
°C:
>58,000 h.
LED backlight lifetime at the
ambient temperature of
+25
°C: >20,000 h.
Active area of
display,
W x H 115.2 x 86.4 mm
Fuse Internal DC fuse, 2.0 AT, 5 x 20 mm
Power supply +24 V DC (20 - 30 V DC). Power supply connector.
CE: The power supply must conform with the requirements according to IEC
60950 and IEC 61558-2-4.
UL and cUL: The power supply must conform with the requirements for class
II power supplies.
