Technical Data
3 Technical Data
Parameter iX T7B
Front panel, W × H × D 204 Ч 143 Ч 7 mm
Cut out dimensions,
W × H
187 × 126 mm
Mounting depth 43 mm (143 mm including clearance)
Standalone mounting VESA 75 × 75
Note: Maximum screw length for VESA mounting is 4 mm.
Usage of longer screws may lead to damage.
Front panel seal IP 65
Rear panel seal IP 20
Touch screen
material Polyester on glass, resistive.
Overlay: Autoflex EBA 180L
(1) .
Touch screen
operations 1 million finger touch operations
Reverse side
material Powder-coated aluminum
Frame material Powder-coated aluminum
Weight 1.010 kg
Serial port for
COM1 RS232 and
COM2 RS422/RS485 9-pin D-sub contact with RS232 RTS/CTS, chassis-mounted
female with standard locking screws 4-40 UNC
Serial port for
COM3 RS232 and
COM4 RS422/RS485 9-pin D-sub contact with RS232 RTS/CTS, chassis-mounted
female with standard locking screws 4-40 UNC
Ethernet 1 × 10/100/1000 Mbit/s and 1 × 10/100 Mbit/s. Shielded
RJ45
USB 3 × USB Host 2.0, max output current 500 mA
Processor Intel® Atom
External storage
media 1 × SD card (optional). Only compatible with the standard SD
format with up to 2 GB storage capacity.
Memory RAM 1 GB
LED 1 × multi-color
Real time clock Yes (on chip)
Battery Lithium battery type BR 2032 (or CR 2032), exchangeable
Power consumption
at rated voltage 14 W
Fuse 3.15 A Slow
Power supply +24 V DC (18-32 V DC)
CE: The power supply must conform with the requirements
according to IEC 60950 and IEC 61558-2-4.
UL and cUL: The power supply must conform with the
requirements for class II power supplies.
Display TFT-LCD with LED backlight. 800 × 480 pixels, 262 k colors
Active area of
display, W × H 152.4 × 91.4 mm
