1424-EN/LZT103 088 Uen F5 2012-03-14 35
DT690 AND DT692 D ESCRIPTION
3.5 Indicators
3.5.1 Phone Indicator
The status indicators listed below are used to indicate phone status.
Table 3 Cordless Phone Indicator
3.5.2 Desk PDM Charger Indicator
The status indicators listed below are used to indicate charger status.
Table 4 Desk PDM Charger Indicator
Indicator Description
Orange, fixed (phone placed in
charger) Battery is being charged.
Green, fixed (phone placed in
charger) Battery is fully charged.
Red, fixed Battery warning.
Green flashing Incoming call.
Indicator Description
None Not connected to power.
Green, fixed Logged on to CPDM3 or
WinPDM.
Orange, fixed Not logged on to CPDM3 or
WinPDM.
Orange, flashing (1000 ms on,
1000 ms off) Software download
File transfer during Easy
Replacement
Orange, flashing (100 ms on, 800
ms off) Change phone indication during
Easy Replacement.
Red, fixed Software error. Service needed.
