Tool Kit
Surface Mounted Installation
*Tools Needed for Installation
Tape Measure
Marker or Pencil
Masonry Drill Bit
Drill (Hammer drill recommended)
Hammer
Wrench 9/16”
Level
Recommended Base materials:
Solid concrete is the best base material for
installation. To ensure the proper anchors are
shipped with your Tool Kit, ask your Tool Kit
representative which anchor is appropriate for your
application. Be sure nothing is underneath the base
material that could be damaged by drilling.
Installation:
3/8” anchors are shipped with the Tool Kit. Place the Tool Kit in the desired location. Use a marker or pencil to outline the
holes of the flange onto the base material. Drill the holes in accordance with the specifications shipped with the anchors.
Make sure the holes are at least 3” away from any cracks in the base material. Use washers to level Tool Kit if necessary. Tap
in anchors and follow your specific anchor instructions provided with the Tool Kit.
Tamper Resistant Hardware:
The concrete spike is a permanent anchor. The top
of the wedge anchor can also be pounded sideways
after installation so that it cannot be removed. Other
tamper resistant fasteners are also available for
purchase.
When using the special tamper resistant nuts, always
set and first tighten the anchors. Once the Tool Kit is
installed, replace two nuts from the Tool Kit
(opposite sides from each other) with the tamper
resistant fastener. DO NOT OVERTIGHTEN the
tamper resistant nut.
1.
2.
3.
4.
Standard Anchor Types
