*Tools Needed for Wall Mount Installation
9/16” Wrench/Socket
Masonry Drill Bit
Tape Measure
Drill (Hammer drill recommended)
Hammer
Level
Marker or pencil
Ultra Space Saver Single
Installation
Recommended Base Materials:
Solid concrete is the best base material. Brick, block, and
wood stud walls may be acceptable. Metal stud walls are
not an acceptable material
for installation. Before installing make sure nothing is
behind the wall that could be damaged by drilling and
that the base material is strong enough to support a fully
loaded rack. Tell your ABS Co. representative what kind
of base material you are installing the Wall Rack into so
the proper anchors can be shipped with the rack.
Installation:
3/8” anchors are shipped with the rack. Place the rack in
the desired location. Use a marker or pencil to outline the
holes of the flange onto the base material. Drill the holes
in accordance with the specifications shipped with the
anchors. Make sure the holes are at least 3” away
from any cracks in the base material.
Tamper Resistant Fasteners:
The concrete spike is a permanent anchor. The top of the
wedge anchor can also be pounded sideways after
installation so that it cannot be removed. Other tamper
resistant fasteners are also available for purchase.
When using the special tamper resistant nuts always set
and first tighten the anchors. Once the rack is installed,
replace two nuts from the bracket (opposite sides from
each other) with the tamper resistant fastener. DO NOT
OVERTIGHTEN the tamper resistant nut.
