6
SPECIFICATIONS
INPUTS
Nominal input level:
+4 dBu (1.23 V rms)
Maximum input level:
+20 dBu (7.75 V rms)
Input impedance:
10 k
Ω
OUTPUT
Low frequency (LF) power:
80 W rms (130 W Peak)
High frequency (HF) power:
40 W rms (130 W Peak)
Max peak SPL per pair:
~113 dBSPL (1m / max input below clipping)
Frequency response:
45 Hz – 20 kHz
±1.5 dB
Bass level:
-3 dB @ 39 Hz typical
POWER REQUIREMENTS
Input voltage:
100 V AC – 230 V AC
Input frequency:
47 – 63 Hz
Power consumption:
20 W idle (150 W peak)
ENVIRONMENTAL REQUIREMENTS
Temperature range:
0-40º C
Relative humidity:
30-85%
(non-condensing)
CABLING REQUIREMENTS
Source to speaker:
Balanced or unbalanced, shielded; XLR or 1/4" TRS connector
MECHANICAL
Size (H x W x D):
17.5" x 11" x 13.5" (445 mm x 280 mm x 345 mm)
Weight:
33
lbs
(15
kg)
