PM16-2 Parts List 3/18/2010
YS # Description Qty. YS # Description Qty. YS # Description Qty. YS # Description Qty. YS # Description Qty.
5906 RED 3MM LED 1V9 20MA.4SPCER T&R 26 5840 _22N 400V 10%CAP BLK RAD POLY FLM 4 2343 6 CIR XH-HEADER RA 0.098IN 2 6124 1/4W 3K 5%MINI T&R RES 44 7634 0.1W 20K5 1% 0805 SMT RES 4
5907 YEL 3MM LED 1V9 20MA.4SPCER T&R 7 6451 __4N7 250V 20%CAP BLK 'Y' 10MM AC 1 3638 12 CIR CABLE HOLDER .098 4 6136 1/4W 3K3 5%MINI T&R RES 2 7693 __1N 50V 5%CAP 0805 SMT NPO 4
5908 GRN 3MM LED 1V9 20MA.4SPCER T&R 20 5212 100N 63V 5%CAP T&R RAD .2FLM 171 4056 2 CIR XH-HEADER 0.098IN 6 4850 1/4W 3K9 5% T&R RES 4 7766 15P 50V 5%CAP 0603 SMT NPO 2
5993 RED 3MM LED 1V9 20MA.12SPCR T&R 5 5226 _68N 100V 5%CAP T&R RAD .2FLM 8 3596 36PIN BREAKAWAY .15GOLD .100 0.66 4681 1.0W 4K7 5% T&R RES 2 7781 W063 49R9 1% 0603 SMT RES 2
5994 YEL 3MM LED 1V9 20MA.12SPCR T&R 8 5230 180N 63V 5%CAP T&R RAD .2FLM 4 3538 24 PIN BREAKAWAY LOCK .156 2.666 4827 1/4W 4K7 5% T&R RES 1 7786 CD4052B IC DUAL 4CHANNEL MUX SMT 2
5995 GRN 3MM LED 1V9 20MA.12SPCR T&R 17 5233 330N 63V 5%CAP T&R RAD .2FLM 28 8397 KNOB STYLE 2 GREY 2 4943 1/4W 4K7 5% .2"U T&R RES 54 7818 LM1117 REGULATOR 3V3 SOT-223 2
6419 BRIDGE 35A 400V WIRE LEAD GI3504 3 5314 100N 50V 10%CAP T&R BEAD X7R 24 8637 ROUND PUSH BUTTON 1/4" BLK 24MM 1 4982 1/4W 4K7 5%MINI T&R RES 157 7853 W250 100R 5% 1206 SMT RES 2
6425 BAV21 200V 0A25 DIODE T&R 56 5240 680N 63V 10%CAP T&R RAD .2FLM 4 8638 KNOB APMIXER PUSHSW BUTTON GREY 51 6128 1/4W 4K99 1%MINI MF T&R RES 112 7882 W063 0R 1% 1206 SMT RES 2
6825 1N4148 75V 0A45 DIODE T&R 231 5254 __1U 63V 20%CAP T&R 4X7MM .2EL 6 8661 KNOB BUTTON FLAT GREY 4 6138 1/4W 5K1 5%MINI T&R RES 2 7912 FV-1 SPIN SEMI REVERB CHIP IC 2
6827 1N5402 200V 3A0 DIODE 4 5255 __1U 63V 20%CAP T&R RAD .2EL 1 8680 KNOB AP-812 GREY FADER 18 6141 1/4W 5K6 5%MINI T&R RES 8 7913 32KHZ CRYSTAL SMT 4-PIN FSRLF 2
6934 MR854 400V 3A0 DIODE FASREC 40 5256 __1U 63V 5%CAP T&R RAD .2FLM 4 9915 KNOB 0-DEG RED SOFT GRAY RIB 16 4628 1/2W 6K8 5% T&R RES 1 7932 07 PIN 25SQ 100 PIN SMT SIL 2
6436 1N753ARL 6V2 0W5 ZENER 5% T&R 1 5257 __2U2 63V 20%CAP T&R RAD .2EL 24 9916 KNOB 0-DEG GRY SOFT GRAY RIB 44 4978 1/4W 6K8 5%MINI T&R RES 12 7933 08 PIN 25SQ 100 PIN SMT SIL 2
6437 1N5237B 8V2 0W5 ZENER 5% T&R 6 5258 __4U7 63V 20%CAP T&R 8X7MM .2EL 4 9917 KNOB 0-DEG GRN SOFT GRAY RIB 36 5020 1/4W 6K8 5% .2U T&R RES 6 7966 __2N7 100V 10%CAP 0805 SMT X7R 4
6439 1N5225B 3V0 0W5 ZENER 5% T&R 11 5266 680N 250V 20%CAP BLK 'X2' 30MM AC 1 9918 KNOB 0-DEG BLU SOFT GRAY RIB 45 4926 1/4W 7K5 5% .2"U T&R RES 38 7934-PROG 24LC32A SER EEPROM MIX2-U3 YS DFX 2
6440 1N750ARL 4V7 0W5 ZENER 5% T&R 1 7769 __1U 50V 20%CAP 4.3X3.9 SMT ELC 10 9919 KNOB 0-DEG YEL SOFT GRAY RIB 14 4955 1/4W 8K2 5% .2"U T&R RES 6 7935-PROG 24LC32A SER EEPROM MIX2-U4 YS DFX 2
6450 1N5242B 12V0 0W5 ZENER 5% T&R 8 5282 _10U 16V 20%CAP T&R 5X7MM .2NP 25 9920 KNOB 0-DEG WHT SOFT GRAY RIB 14 4990 1/4W 8K2 5%MINI T&R RES 6 2350 SNAP IEC PWR SOC W/.250TAB FOR 2MM 1
6459 1N4732A 4V7 1W0 ZENER 5% T&R 1 5631 _22U 50V 20%CAP T&R 6X7MM .2EL 38 3426 8' 3/16 SJT AC LINE CORD REMOVB-CSA 1 4829 1/4W 10K 5% T&R RES 6 8608 NYLON SPACER .200 OD .145 ID .110 L 32
6461 1N5240BRL 10V0 0W5 ZENER 5% T&R 8 5945 _10U 63V 20%CAP T&R RAD .2EL 7 8701 4-40 KEPS NUT ZINC 1 4940 1/4W 10K 5% .2"U T&R RES 64 3751 SNAP IN 5/16 SPACER RICHCO 3
6465 1N5250B 20V0 0W5 ZENER 5% T&R 2 5961 _33U 16V 20%CAP T&R RAD .2 117 2331 6-32 X 3/8" PEM THRD SPACER 0.213 11 4983 1/4W 10K 5%MINI T&R RES 67 3744 SNAP IN .375 SPACER RICHCO 18
6475 1N5262B 51V0 0W5 ZENER 5% T&R 1 7810 _47U 16V 20%CAP 6X5.4 SMT ELE 4 2332 6-32 X 5/8" PEM THRD SPACER 0.281 11 5031 1.0W 10K0 5% T&R RES 34 2335 NYLON STANDOFF NUT #4 500MIL 27
6484 1N4740A 10V0 1W0 ZENER 5% T&R 4 5618 470U 25V 20%CAP BLK 10X15MM EL 2 2346 6-32 X 3/8" PEM BLD THRSPCR 0.213 8 6116 1/4W 10K0 1%MINI MF T&R RES 160 3743 SNAP ON 0.5" SPACER RICHCO 8
6488 1N5236BRL 7V5 0W5 ZENER 5% T&R 22 5879 100U 16V 20%CAP T&R 8X7MM .2EL 36 8760 6-32 KEPS NUT TIN PLATED 32 4979 1/4W 15K 5%MINI T&R RES 36 2342 NYLON STANDOFF NUT #4 530MIL BLK 7
6738 MC7805CT TO220 P 5V0 REG 36V 2 5897 330U 16V 20%CAP BLK 08X11MM EL 4 8800 6-32 KEPS NUT ZINC 10 4954 1/4W 18K 5% .2"U T&R RES 7 2345 NYLON STANDOFF NUT #4 1INCH 1
6824 1N5246B 16V0 0W5 ZENER 5% T&R 32 5635 1000U 35V 20%CAP BLK RADIAL ELECT 6 8787 8-32 KEPS NUT ZINC 10 6125 1/4W 18K 5%MINI T&R RES 11 8482 3/8 1D FLAT WASHER 45
6871 MC7915CT TO220 N 15V0 REG V2 2 5896 4700U 80V 20%CAP BLK 25X50MM ELS 6 2351 1032 X 7/16 PEM THRD SPCR SS .281 4 4885 1/4W 20K 5% T&R RES 1 8488 3/8 INT TOOTH LOCKWASHE ZINC 1
6872 MC7815CT TO220 P 15V0 REG V1 2 5898 8200U 50V 20%CAP 25X50MM ELS 12 8841 10-32 KEPS NUT TIN PLATED 12 6123 1/4W 20K0 1%MINI MF T&R RES 8 3517 NYLON WASHER #8 0.062 1
5101 BC550C TO92 NPN TRAN T&R TB 76 6578 ROT BIN 18MM 4BIT ENCODER P23 2 8683 1/4-20 NYLON INSERT NUT ZINC 2 4777 1/4W 21K5 1% T&R RES 4 8818 3/4 OD X 3/8 ID X .080 THICK WASHER 3
5102 BC560C TO92 PNP TRAN T&R TB 37 4384 __5K B LIN 9MM P25 70 8797 5/16-18 KEPS NUT JS500 1 6118 1/4W 22K 5%MINI T&R RES 22 3511 #6 FLAT WASHER NYLON 4
5103 MPSA06 TO92 NPN TRAN T&R TA 12 4434 _10K B LIN 9MM DETENT P32 2 4022 ELASTOMER PAD - 2-TO218 / 4-TO220 12 6129 1/4W 27K 5%MINI T&R RES 18 8485 #6 SPLIT WASHER ZINC 8
5104 MPSA56 TO92 PNP TRAN T&R TA 12 4537 _10K B LIN 9MM DETENT P25 50 2326 LITEPIPE CLEAR L.54" D.125" 12 4840 1/4W 33K 5% T&R RES 4 8820 #8 FLAT WASHER JS500 4
5105 MPSA13 TO92 NPN DARL T&R TA 14 4562 _10K LIN 12MM STEREO DETENTP21 6 4597 22AWG STRAN TC WIR JMP 104 4947 1/4W 33K 5% .2"U T&R RES 22 8817 #10 FLAT WASHER FOR 3/16" BOLT 2
5106 MPSA63 TO92 PNP DARL T&R TA 4 4566 _10K B LIN 9MM P25 18 4599 22AWG SOLID SC WIR T&R JMP 615 6122 1/4W 33K 5%MINI T&R RES 27 2336 NYLON SH/WASHER ID385 OD680 T060 8
5107 2N5551 TO92 NPN TRAN T&R TA 4 4569 _10K LIN 12MM STEREO P21 6 5299 24AWG SOLID SC WIR RAD JMP 11 4878 1/4W 43K 5% T&R RES 8 3577 FIBER WASHER .625OD .380ID .03 8
5108 2N5401 TO92 PNP TRAN T&R TA 8 4545 _50K LIN 12MM STEREO DETENTP21 2 4745 5.0W 0R1 5% BLK RES 16 4927 1/4W 47K 5% .2"U T&R RES 57 3436 DPDT PUSH SW PCMT H BREAK B4 MAKE 1
5113 MPSA42 TO92 NPN TRAN T&R TA 4 4568 _50K B LIN 9MM P25 3 2006 1.0W 1R 5%FLAME PROOF T&R RES 10 6119 1/4W 47K 5%MINI T&R RES 84 3440 4PDT MINI VERT ALT SWITCH 2
6808 MJE15032 TO220 NPN TRAN TE 4 4385 100K 5C R/A 12MM STEREO P21 12 2007 1/4W 1R 5%FLAME PROOF T&R RES 8 4835 1/4W 56K 5% T&R RES 4 3522 DPDT MINI PC VERT SNP ALT 47
6809 MJE15033 TO220 PNP TRAN TE 4 4487 _10K 10A AUD 60MM STEREO S01 2 4911 1/4W 2R2 5% T&R RES 8 5018 1/4W 56K 5%MINI T&R RES 20 3587 DPDT ROKR SW QUIK 250"AC/PWR ON-OFF 1
6873 MJE340 TO126 NPN TRAN TG 4 4489 _10K B LIN 60MM S01 12 4918 1/4W 3R3 5% T&R RES 4 4586 1/4W 82K 5%MINI T&R RES 22 3682 250 MALE PCB TAB REEL 22
6874 MJE350 TO126 PNP TRAN TG 4 3995 _20K 1B LIN 30MM STEREO DETENTS13 9 4748 2.0W 3R9 5% T&R 4 4929 1/4W 82K 5% .2"U T&R RES 6 3009 PATCH 02 22AWG 16.5 XH TWST FANCORD 1
6902 TIP142 TO247 NPN TRAN DARL TE 1 3998 _20K 1B LIN 20MM DETENT S04 18 2008 1.0W 10R 5%FLAME PROOF T&R RES 8 4942 1/4W 100K 5% .2"U T&R RES 10 3033 PATCH 04 22AWG 12.0 156 2
6916 TIP107 TO220 PNP TRAN DARL TE 2 4488 _50K B LIN 60MM S01 4 4709 5.0W 22R 5% BLK RES 3 6120 1/4W 100K 5%MINI T&R RES 41 3044 PATCH 06 22AWG 07.0 XH 2
6953 IRF4905 TO220 PCH MFET 16 4520 _10K TRIM POT 4 2013 1/8W 22R1 1%FLAME PROOF T&R RES 4 4851 1/4W 120K 5% T&R RES 7 3027 PATCH 06 22AWG 12.0 XH 1
6966 IRL2910 NCH MFET 100V TN 16 2448 15.00 AMP CIRCUIT BREAKER 1 2016 1/8W 39R 2%FLAME PROOF T&R RES 8 4991 1/4W 133K 1%MINI T&R RES 8 3028 PATCH 08 22AWG 18.0 XH 1
6909 MJ21196 TO3 NPN TRAN TH 8 2333 SQR SNAP 17X14MM BUSHING 4 4613 1.0W 47R 5% T&R RES 4 4949 1/4W 180K 5% .2"U T&R RES 2 3029 PATCH 12 22AWG 16.0 XH 1
6910 MJ21195 TO3 PNP TRANSISTOR TH 8 2349 RCT SNAP 13X05MM WIRE CLAMP 2 4617 1/2W 47R 5% T&R RES 8 4841 1/4W 220K 5% T&R RES 6 3030 PATCH 12 22AWG 25.0 XH 1
6745 LM13600N IC XCONDUCTANCE AMP 5 3820 ___4UH COIL 14AWG ZOBEL HORIZONTAL 4 4817 1/4W 47R 5% T&R RES 3 6126 1/4W 220K 5%MINI T&R RES 16 3031 PATCH 14 22AWG 20.0 XH 1
6804 MC33079P IC QUAD OP AMP 1 8547 PLASTIC FOOT BLACK, POLYETHYLENE 8 4957 1/4W 47R 5% .2"U T&R RES 3 6127 1/4W 470K 5%MINI T&R RES 5 3047 PATCH 15 22AWG 18.0 XH TWST4&5-8&9 2
6840 MC33078P IC DUAL OP AMP 7 3470 CLIP 250X032 14-16AWG DISCO-LOK 2 6134 1/4W 47R 5%MINI T&R RES 18 4948 1/4W 1M 5% .2"U T&R RES 14 CH1200U PM16/22-2 120-230VAC 60HZ T'RD 1
6882 TL072CP IC FET DUAL OP AMP 17 3486 CLIP 250X032 22-18AWG DISCO-LOK 1 2019 1/8W 100R0 1%FLAME PROOF T&R RES 40 4888 1/4W 4M7 5% T&R RES 9
6884 NE5532N IC DUAL OP AMP 22 3490 CLIP 250X032 14-16AWG DISCO/INSL 11 4602 1/8W 100R 5% T&R RES 59 4951 1/4W 4M7 5% .2"U T&R RES 13
6889 TL074CN IC QUAD O/A T.I ONLY 25 3601 RING TERMINAL 16AWG WIRE & #8 SCREW 5 4921 1/4W 100R 5% .2"U T&R RES 3 4809 1/4W 10M 5% T&R RES 4
6895 BA6822S IC LED VU METER C 1 3926 BNC FEMALE PANEL MNT NON-INSUL 1 4984 1/4W 150R 5%MINI T&R RES 4 4751 1/4W 22M 5% T&R RES 30
6959 4052 IC DUAL 1\4 CMOS SWITC 1 3498 1/4" JCK PCB MT HORZ 1 2023 1/8W 220R0 1%FLAME PROOF T&R RES 16 3639 _1.7"12C-26AWG RIBBON 0.25"S&R 098" 0.5
6467 _10K 10% THERMISTOR TO-92 NTC 4 3921 1/4" JCK PCB MT VERT STER RT SWT 37 4944 1/4W 220R 5% .2"U T&R RES 6 4068 1.75"12C-26AWG RIB SLOT 0.25"S&R.1" 2
6489 __5R 20% THERMISTOR-SURGR NTC 2 3924 1/4" JCK PCB MT VERT 2XTIP HICURNT 8 4977 1/4W 220R 5%MINI T&R RES 36 3721 RELAY 1A 16AMP DC24 022MA PC-C 1
5197 220P 100V 2%CAP T&R RAD CER.2NPO 12 3466 RCA DUAL PCB MT VERT GOLD 24MM 3 4884 1/4W 240R 5% T&R RES 1 3722 RELAY 1A 30AMP DC24 036MA PC-C 4
5199 100P 100V 2%CAP T&R RAD CER.2NPO 26 3628 SPKON 4C PCB MT VERT 250TAB GRY #4 4 2024 1/8W 249R 2%FLAME PROOF T&R RES 24 8842 #4 X 5/16 PAN QUAD TYPE A JS500 BLK 27
5203 _47P 100V 2%CAP T&R RAD CER.2NPO 13 2312 6-32 SCRW TERM VERT PC MNT 0.165IN 28 4872 1/4W 390R 5% T&R RES 4 8865 4-40 X 5/16 PAN PH MS JS500 1
5410 100P 100V 10%CAP T&R BEAD NPO 6 2325 SKS-50T PLASTIC FOOT 2 4713 1.0W 470R 5% T&R RES 1 8729 #4 X 3/8 FLAT QUAD TYPE A JS500 BLK 8
5412 220P 100V 10%CAP T&R BEAD NPO 6 4010 XLR FEML PCB MT VERT 24MM AA-SERIES 12 4821 1/4W 470R 5% T&R RES 2 8808 4-40 X 3/4 FLAT PHIL MS B.O.& WAX 34
5417 330P 50V 10%CAP T&R BEAD NPO 4 3451 EYELET SMALL 0.089 OD PLATED 52 4933 1/4W 470R 5% .2"U T&R RES 3 8819 4-40 X 1.25 FLAT PH MS BLK ROHS 1
5201 470P 100V 5%CAP T&R RAD CER.2NPO 6 3414 INTERNATIONAL PC MOUNT FUSEHOLDER 2 4980 1/4W 470R 5%MINI T&R RES 35 8822 6-32 X 1/4 PAN PH MS ZN C/W SPLIT_W 28
5206 __1N 400V 5%CAP T&R RAD .2FLM 4 2487 _7.0 AMP SLO-BLO T&R FUSE 2 4799 1/4W 562R 1% T&R RES 32 8832 6-32 X 1/4 PAN PH TAPTITE JS500 77
5273 __1N5 200V 5%CAP T&R RAD CER.2NPO 12 3856 FAN 80MM X 80MM 39CFM 12VDC 200MA 4 5019 1/4W 620R 5%MINI T&R RES 36 8801 6-32 X 3/8 PAN PH TAPTITE JS500 1
5274 __2N2 200V 5%CAP T&R RAD CER.2NPO 4 8436 10" CONTOUR HANDLE BLK METAL ENDCAP 1 4873 1/4W 680R 5% T&R RES 8 8829 6-32 X 3/8 FLAT PH TAPTITE BO#C HEA 34
5416 470P 50V 10%CAP T&R BEAD NPO 18 3078 5/16-18 NYLON HEX NUT 1 2030 1/8W 681R 1%FLAME PROOF T&R RES 8 8761 6-32 X 1/2 PAN PHIL MS ZINC CLEAR 32
5422 __1N 50V 10%CAP T&R BEAD NPO 25 3894 AAVID 5972-B H/S W/TAB B.O. 8 4869 1/4W 750R 5% T&R RES 4 8837 6-32 X 1/2 ROUND PH MS JS500 12
5424 __1N5 50V 10%CAP T&R BEAD Y5P 4 6583 BRDLK TO220 H/S W/TAB B.O. 5 4925 1/4W 820R 5% .2"U T&R RES 4 8828 6-32 X 3/4 PAN PH TAPTITE JS500 10
5425 __1N8 50V 10%CAP T&R BEAD X7R 2 3501 B52200F006 COMP WASH #4 SMALL 1 2033 1/8W 1K 2%FLAME PROOF T&R RES 8 8830 6-32 X 7/8 PAN PH MS JS500 14
5426 __2N2 50V 10%CAP T&R BEAD Y5R 4 3719 DUAL XSISTOR SPRING, ZINC CLEAR 2 4934 1/4W 1K 5% .2"U T&R RES 8 8763 8-32 X 1/2 PAN PH MS JS500 BLACK 6
5204 _10N 100V 10%CAP T&R RAD .2FLM 12 3977 QUAD XSISTOR SPRING, ZINC YELLOW 12 4981 1/4W 1K 5%MINI T&R RES 20 8815 8-32 X 3/4 PAN PH TAPTITE JS500 2
5207 _18N 100V 5%CAP T&R RAD .2FLM 4 4082 BELLVILLE WASH .5X.255X.025 93LB 2 6110 1/4W 1K0 1%MINI MF T&R RES 4 8809 10-32 X 1/4 PAN PH TAPTITE JS500 16
5209 __4N7 250V 5%CAP T&R RAD .2FLM 16 3810 4" NYLON CABLE TIE 20 4585 1/4W 1K2 5%MINI T&R RES 72 8868 10-32 1/2" FLAT PH 82' CS TT JS500 12
5210 _22N 100V 10%CAP T&R RAD .2FLM 30 1155 3.3X.6X.6 TAPPED BRACKET 12 4824 1/4W 1K5 5% T&R RES 2 8833 10-32 X 7/8 IND HEX M/S BLACK OXIDE 12
5222 _33N 100V 10%CAP T&R RAD .2FLM 12 3597 12 CIR HDR BOT ENTRY 0.1" GOLD 2 4988 1/4W 1K5 5%MINI T&R RES 20 8770 1/4-20 X 1 5/16 TRUSS PH MS JS500 2
5224 _47N 100V 10%CAP T&R RAD .2FLM 6 2310 15 CIR XH-HEADER 0.098IN 4 6105 1/4W 1K8 5%MINI T&R RES 8 8926 5/16-18X3 CARRIAGE BOLT ZINC 1
5271 __5N6 100V 5%CAP T&R RAD .2F 12 2327 6 CIR XH-HEADER 0.098IN 4 4946 1/4W 2K 5% .2"U T&R RES 12 7613 100N 25V 10%CAP 0805 SMT X7R 10
5300 _10N 50V 10%CAP T&R BEAD X7R 1 2328 8 CIR XH-HEADER 0.098IN 2 6113 1/4W 2K 5%MINI T&R RES 75 7621 0.1W 1K0 1% 0805 SMT RES 8
5308 _47N 50V 10%CAP T&R BEAD X7R 2 2329 12 CIR XH-HEADER 0.098IN 4 6104 1/4W 2K2 5%MINI T&R RES 10 7624 0.1W 100R 1% 0805 SMT RES 2
5433 __5N6 50V 10%CAP T&R BEAD X7R 4 2330 14 CIR XH-HEADER 0.098IN 2 4864 1/4W 2K7 5% T&R RES 2 7625 0.1W 10K0 1% 0805 SMT RES 10
