Specifications
Model:
MM5D Powered Box Mixer
Model ID:
MM5D
Number of Channels:
5
Mono Channel EQ:
2-band shelving
Channel Effects:
Yes
Inputs - XLR (bal):
Ch. 1-5
Inputs - 1/4-inch:
Ch. 1-5
Inputs - RCA (unbal):
Tape/CD in
Internal Effects:
16 Digital Effects: reverb, echo, chorus, flange
External Effects Send:
no
External Effects Return:
no
Effects Return to Main:
Yes
Record Outputs RCA (unbal):
Record Out with Level Control
Max Gain to Amplifier Out -Mic Input (dB):
84
Max Gain to Amplifier Out -Line Input (dB):
70
Main Outputs ( Line Level):
n.a.
Outputs - Amp A/B - Speakon / 1/4-inch Jacks:
1/1
Mixer - Frequency Response (Tone and EQ Flat,+/-2dB):
40-20000 Hz
Amp A/B - Power Output @ 8 Ohms (0.1% THD, 1kHz):
2 x 60 watts
Amp A/B - Power Output @ 4 ohms:
2 x 90 watts
THD - 20Hz-20kHz (dB):
less than 0.1%
Power Consumption (typ/max):
1.0 A @ 120VAC / 0.5 A @ 240VAC
Protection:
Clip limiter, thermal shutdown
Cooling:
Passive heatsink and internal Fan
Dimensions (DWH, inches):
9x17.75x6
Dimensions (DWH, cm):
22.85x45x15.25
Weight (lbs/kg):
19.2 / 9.7
