Yorkville PSA1 - Manual (Page 3)

Specifications
Active or Passive Active
Program Power (watts) 700 Program (1200 watts Peak)
Biampable Biamp
Max SPL (dB) 128dB Peak (125dB Continuous)
Frequency Response (Hz +/- 3db) 75Hz-20K
Crossover Frequency (Hz) 1.2K
Driver Configuration 2x1", 4x6"
HF Driver(s) 2x1-inch Ceramic w/ 1.75-inch VoiceCoil
HF Program Power (watts) 75 watts (200 watts Peak)
HF Dispersion (°H x °V) 110x15
HF Protection Peak and Average Limiting
LF Driver(s) 4x6-inch neo with 45mm VC
LF Program Power(watts) 675 watts Program (1000 watts Peak)
LF Impedance(ohms) 2 ohm Load
LF Protection Excursion, RMS
HF Power Amplifier (watts) 75W
HF Amplifier Type 2-Tier Class H
LF Power Amplifier (watts) 625W
LF Amplifier Type Class D
Cooling Scheme Convection
Power Cable Removable Locking IEC Input and Loop Thru Output
Power Switch Yes
Power Consumption (typ/max) 135 VA / 225 VA
Inputs 1 Combijack (XLR / 1/4-inch)
Input Sensitivity (Vrms Sine) Line in 1.4 at center, 0.35 at max
Level Controls Volume
EQ Controls HF Boost switch, Fullrange/Sub switch
Limiter Peak and Average limiting on horn and woofer
LED Indicators Power, Limit, Clip
Enclosure Materials Injection Molded ABS
Baffle Material Injection Molded ABS
Covering / Finish Paint
Optional Covering / Finishes Optional Colours available
Dimensions (DWH xbackW, inches) 14.5 x20.5 x16
Dimensions (DWH xbackW, cm) 36.8 x 52.1 x 40.6
Weight (lbs/kg) 47 / 21.4
* Specifications subject to change without notice
