Layout-m1209-ex2-pwrsupply 2/3 – Yorkville EX2 User Manual
Page 16
3. ADD RTV ALL AROUND C70
PRODUCTION NOTES
SEE LAYOUT DIAGRAM
4. Auto Insert do not stuff C11 & C12, B.A. will put #5880,100U 35V.
1. Hardware for mounting devices to heatspreader:
4-40 screw part# 8741, washer part# 3501,
mica grease, kepnut part# 8701
2. ADD RTV TO 3 SIDES OF BIG COIL (LOOK AT L6
TO SEE ARROWS OF WHERE TO APPLY)
